C Series Wireless Bridge

Your Professional C Series Wireless Bridge Manufacturer!

Jinan Boda Xun Communication Technology Co., Ltd. is a professional wireless communication technology manufacturer, specializing in the research, development, production, and sales of wireless network equipment and solutions. Since its establishment in 2011, we have been committed to driving innovation and providing reliable connectivity solutions for various industries.Our product portfolio covers industrial WiFi coverage, wireless bridges, industrial routers, VPN equipment, and long-distance wireless communication systems, designed to meet diverse networking requirements in industrial environments.

Wireless Alternative To Fiber Deployment
BodaCOM 4131 CRT18 is a compact outdoor Sub-6GHz fixed wireless access (FWA) unit featuring an integrated 18 dBi high-gain directional antenna, engineered for efficient medium-range broadband...
read more
Outdoor Wireless Access
BodaCOM 4131 CRTF2 is a high-performance outdoor Sub-6GHz wireless broadband system, also an excellent outdoor wireless access device, designed for scalable Point-to-Multipoint (PtMP) and...
read more
Wireless Backhaul
BodaCOM 4131 CRT23 is a high-gain outdoor Long-Range Fixed Wireless Unit equipped with an integrated 23 dBi High-Gain Directional Antenna, engineered for extended-distance wireless transmission...
read more

Why Choose Us

01.

High Quality

We operate a 1,000 m² modern factory that integrates intelligent production, R&D testing, and warehousing logistics. From motherboard and mold design to final product testing, the entire process is vertically integrated and strictly controlled to ensure stable quality and efficient production.

02.

Advanced Equipment

Our facility is equipped with a range of specialized production and testing equipment, including RF testers, network analyzers, AOI inspection systems, and environmental testing chambers. These tools support consistent manufacturing standards and help ensure reliable product performance.

03.

Our Certificate

Our company holds multiple wireless communication invention patents and software copyrights, and has obtained ISO9001 quality management system certification, ISO14001 environmental management system certification, and ISO4500 occupational health and safety management system certification.

04.

Our Service

We provide professional support throughout the product lifecycle, including pre-sales solution consulting, installation guidance and training during deployment, and after-sales services such as 7×24 response, remote monitoring, and regular firmware updates.

Advantages of C Series Wireless Bridge

High-Speed, Reliable Wireless Backhaul
The C-Series wireless bridge ensures fast and stable data transmission for backhaul connections, making it an ideal solution for high-bandwidth applications like video surveillance, remote offices, and large-scale networks.

Versatile Outdoor Wireless Access
Designed to provide seamless outdoor wireless connectivity, the C-Series supports various environments, from urban areas to remote regions, offering reliable internet access for businesses and communities.

Interference-Resistant Design
Featuring cutting-edge anti-interference technology, the C-Series maintains superior performance even in challenging electromagnetic environments, ensuring reliable data transmission without disruptions.

Flexible Installation Options
The C-Series bridge offers flexible mounting options, such as tower and rooftop installations, allowing for easy and quick setup in different deployment scenarios, whether for short or long-range coverage.

Built for Harsh Environments
The C-Series is engineered to perform in tough conditions, with rugged hardware that withstands harsh weather and interference, making it suitable for both urban and rural deployments.

Applications of C Series Wireless Bridge

Warehousing and Logistics

Power Transmission and Transformation

Integrated Utility Tunnels

Rail Transportation

Smart Border Security

Ferry Services

Technical Specifications

Product model	BodaCOM 4131 CRT23
Radio
Architecture	Outdoor Unit connectorized for external antenna (2 x N-type)
Antenna gain	23 dBi
Range	Up to 15 km / 9 miles
Wireless topology PtMP base station	PtMP Base Station / PtMP Remote Station / PtP Base Station / PtP Remote
Frequency band and regulation	Universal (4.9-6GHz), ETSI, FCC (5.1, 5.8GHz) WPC, IC (5.8GHz)
Radio access scheme	OFDM, Auto MIMO 2x2
Adaptive Modulation	MIMO-OFDM(BPSK/QPSK/16QAM/64QAM/256QAM)
Encryption	WPA/WPA2 PSK EAP AES128
Duplex Technology	TDD, Configurable Uplink/Downlink ratio
Max Tx Power	30 dBm per radio per port
Channel Bandwidth	Configurable: 10, 20, 40, 80 MHz , automatic selection between 20,40,80MHz
Interfaces
Data Interfaces	1000BaseT (over PoE)
PoE to ODU Interface	Outdoor CAT-5e; Maximum cable length: 75m for 1000BaseT
Networking
Sub convergence layer	Layer 2, Bridging learning of 8K MAC addresses
QOS	Packet classification to 4 priority queues according to 802.1P or Diffserv
VLAN Support	802.1Q, QinQ, 4094 VLANs
Management
Protocol	IPv4/IPv6 dual-stack; SNMP v1/v3; HTTP/HTTPS; Telnet
SNMP	Support SNMP v1, v2c and v3
NMS application	BodaCOM Config
Mechanical
ODU Dimensions	370mm370mm89.5mm
ODU Weight	Approx. 3.9 kg
Power
Power Feeding	Provided over PoE cable
Power Consumption	≤12W
Environmental
Operating Temperatures	-40°C to 60°C / -31°F to 140°F
Humidity	100% condensing
Protection	IP68;anti-corrosion, dustproof, waterproof, UV-resistant, salt spray resistant

Networking Methods

Through the following two core networking modes, we can build a more forward-looking wireless network blueprint for you, specifically tailored to your concrete application scenarios:
1. Point-to-Multipoint (PtMP) Network: Efficient Coverage and Rapid Expansion

2. Point-to-Point (PtP) & Relay Network: Breaking Distance Barriers, Unfazed by Complex Terrain

Packing & Delivery

Packing in cartons regularly.
Shipping & Trade terms:You can choose your own forwarder, also can use our forwarder to ship by sea, air, or UPS, FEDEX, EMS,DHL,etc.
Trade terms: EXW, FOB etc.
Delivered time: 2-3 business days for sample, 30-35 days for mass order.

FAQ

Q: Can l customize the product?

A: Yes.We can customize to your and make your own brand logo. Also we can the package theproducts according to your request.We can accept OEM orders.

Q: Can I have a sample order?

A: Yes ,we welcome sample order to test and check quality.

Q: Is it easy to set up your items?

A: Yes.We have a user manual and support technical support 24/7

Q: What is your warranty time?

A: We promise 1-year warranty for all products shipped from us.Man-made sabotage and natural factors are not within the scope of warranty.

Q: What is your lead time?

A: Production time typically ranges from 3 to 5 days after receiving your deposit. The actual delivery time will depend on the items ordered and the quantity, with larger orders being processed more quickly.

Q: Is the wireless bridge signal stable?

A: In unobstructed and properly aligned conditions, the signal stability is close to that of a wired connection. It is widely used in surveillance and remote office applications.

Q: Can a home WiFi router be used as a wireless bridge?

A: Theoretically, some routers that support WDS or bridge mode can achieve similar functions, but it is not recommended for use as a professional wireless bridge due to insufficient signal strength and reliability.

Q: Does a wireless bridge limit speed?

A: Limited by bandwidth, frequency band interference, and hardware specifications, it is recommended to choose models that support AC1200 or higher specifications to ensure a transmission rate of at least 100Mbps.

Q: How do wireless bridges work?

A: Wireless bridges use point to point technology to wirelessly connect two end points together. By using high frequency radio waves, wireless bridges can now transfer data up to 20Gbps (full duplex).

Q: What is a wireless bridge used for?

A: Most commonly, wireless bridges are used to connect: buildings, CCTV cameras, sensors, telecommunication masts, corporate WAN connections, internet access or anything else that requires a data connection.

With abundant experience, we are one of the most professional c series wireless bridge manufacturers and suppliers in China. Please rest assured to buy high quality c series wireless bridge for sale here from our factory. For price consultation, contact us.

c series wireless bridge, Wireless Alternative To Fiber Deployment, Wireless Backhaul
