Wireless Link Simulation
Clearer Planning More Reliable Solutions
Supports PTP, PTMP, and WiFi coverage design. From site placement and device parameters to terrain profiles and professional reports, evaluate wireless links on a single map.
Planning Coverage
|
PTP Link |
PTMP Planning |
WiFi Coverage |
|
Plan and compare a point-to-point link in both directions. |
Calculate independent links for multiple remote sites. |
Place devices and calculate coverage area and rate. |
Planning Advantages
|
Two Way Calculation |
Terrain Analysis |
Reusable Designs |
|
Independent A-to-B and B-to-A results |
Line of sight and Fresnel zone review |
Save, reuse, and export reports |
Five Core Capabilities
The platform combines link calculation, terrain review, WiFi coverage planning, and project reporting in one workflow.
|
No |
Capability |
What it provides |
|
01 |
PTP Two Way Link Budget |
Calculate power, margin, SNR, and throughput for A-to-B and B-to-A. |
|
02 |
PTMP Multi Remote Planning |
Calculate each remote link independently and summarize demand and shared capacity. |
|
03 |
Terrain and Fresnel Zone Analysis |
Analyze terrain, curvature, line of sight, Fresnel zone, and minimum clearance. |
|
04 |
WiFi Coverage Design |
Set device coverage and project boundaries, then calculate coverage area and rate. |
|
05 |
Project Management and Report Output |
Save sites, groups, and designs; preview, print, and export reports. |
One Platform Three Planning Modes
|
PTP Planning Two-way link budget and result comparison |
PTMP Plan Per-link calculations for multiple remotes |
WiFi Coverage Device placement and coverage metrics |
Ideal applications include campus backhaul, rural broadband, industrial sites, surveillance, campus WiFi, and remote-site planning.
More Than Just a Number
The assessment for planning purposes requires calculation. The final plan should incorporate on-site surveys, compliance with regulations, and verification of actual equipment parameters.
Engineered Planning from Sites to Reports
|
01 Clear One interface with three design modes |
02 Intuitive Map, profile, and results |
03 Reusable Reusable groups and site library |
|
04 Comparable Two-way and multi-remote comparisons |
05 Delivery Preview reports and export PDF |
06 Local Data Offline terrain for decisions |
Standard Workflow
Plan in six steps from project setup to report delivery.
|
01 Create Project |
02 Import Sites |
|
03 Select Mode |
04 Set Device Parameters |
|
05 Calculate and Analyze |
06 Export Report |
